BUILT: 2017
CLASS: LRS
FLAG: MARSHALL ISLANDS
BUILDER: Daehan Shipbuilding Co. Ltd, S.Korea
VESSEL PARTICULARS
Type of vessel:
100A1, Double Hull Oil Tanker, CSR, ESP, ShipRight (ACS(B,C) CM), Ice Class 1C FS, *IWS, LI, DSPM4, ECO (BWT, IBTS, IHM,P, SEEMP, VECS-L), *LMC, UMS, IGS, COW(LR), ETA, ShipRight (BWMP(S,T), SERS, SCM
Summer deadweight:
112,800 MTS
Summer draft:
15.023 m
Summer freeboard:
5.669 m
GRT / NRT:
60,751.00 / 35,896.00
LOA:
249.90 m
Beam:
44.00 m
Depth:
20.65 m
Keel to mast:
49.00 m
CARGO ARRANGEMENTS
Cargo / slop tanks:
12 / 2
Cargo capacity (98% ex slop tanks):
120,891.50 m³
Slop tank capacity (98%):
2,700.60 m³
Cargo tank coating:
Phenolic epoxy
Heating arrangement:
Heating Coils
SBT / IGS / COW:
Yes
Number of manifolds on each side:
7
Distance bow to mid-point manifold:
124.78 m
Distance main deck to center manifold:
2100 mm
Distance manifolds to ship's rail:
4600 mm
Natural segregation with double valves:
6 + 1
Cranes / SWL:
2 x 15 T
CARGO PUMPS
Cargo pump type:
CENTRIFUGAL VERTICAL SINGLE STAGE
Number of cargo pumps:
3
Capacity of cargo pumps:
3 x 3000
PROPULSION
Main engine:
MAN B AND W 6G60ME-C 9,5 8390 KILOWATT
Propeller type:
Fixed pitch
Generators:
3 X 900 KILOWATT STX
Bow thruster:
N/A
