ARISTOKLIS
BUILT: 2026
CLASS: LRS
FLAG: MARSHALL ISLANDS
BUILDER: New Times Shipbuilding Co., Ltd
VESSEL PARTICULARS
Type of vessel:
CRUDE OIL/PRODUCT CARRIER, +100A1 Double Hull Oil Tanker, CSR, ESP,Occasional Helicopter Landing Area, ShipRight(CM, ACS(B, C)), *IWS, LI, DSPM4, ECO(EAL,GW, IBTS, P, VECS-L), Ice Class 1C FS, +LMCIGS, UMS, BWTS, EGCN (SCR), EGCS (Open,Partial), LFPF(GF,NG), OPS, NAV1
Summer deadweight:
155,374 MT
Summer draft:
17.17 m
Summer freeboard:
6.07 m
GRT / NRT:
84648 / 52220
LOA:
274.39 m
Beam:
48.00 m
Depth:
23.20 m
Keel to mast:
51.14 m (49.84 m Keel to Mast in collapsed condition)
CARGO ARRANGEMENTS
Cargo / slop tanks:
12 / 2
Cargo capacity (98% ex slop tanks):
167850.30 m3
Slop tank capacity (98%):
3548.10 m3
Cargo tank coating:
Epoxy bottom and above up to 0.5m
Heating arrangement:
Aluminized-brass heating Coils in all cargo oil tanks and slop tanks
SBT / IGS / COW:
Yes
Number of manifolds on each side:
3 x 16 Inches(400mm)
Distance bow to mid-point manifold:
135.07 m
Distance main deck to center manifold:
2,100 mm
Distance manifolds to ship's rail:
4,275 mm
Natural segregation with double valves:
3
Cranes / SWL:
2 x 20 T
CARGO PUMPS
Cargo pump type:
Centrifugal
Number of cargo pumps:
3
Capacity of cargo pumps:
3 x 4000 m3/h
PROPULSION
Main engine:
HYUNDAI-MAN B&W 6G70ME C10.5-GI / 13500 Kw
Propeller type:
Fixed pitch
Generators:
3 x YANMAR 6EY22ALWS / 1250 Kw
Bow thruster:
N/A
